ON Semiconductor Introduces New Power Modules for Greater Efficiency and Space

On November 8, 2018, ON Semiconductor (Nasdaq: ON), which promotes energy-efficient innovation, introduced new power modules that deliver superior energy efficiency, reliability and reliability in a highly integrated and compact package. Performance has been added to the company's already strong lineup of power semiconductor devices.

Power stages in applications such as solar inverters, uninterrupted power supply (UPS) inverters, and industrial variable frequency drives (VFDs) typically consist of discrete IGBT/MOSFET integrated dedicated drivers and additional discrete components. ON Semiconductor's new NXH160T120L2Q1SG and NXH160T120L2Q2F2SG Power Integration Modules (PIMs) provide a compact, highly integrated solution that saves space and reduces costs in an easy-to-place package that greatly decreases designer challenges.

Available in Q1 and Q2 packages for 30 kW and 50 KW inverters, integrated field-stop trench IGBTs and fast recovery diodes provide lower turn-on and switching losses and enable designers to achieve low VCE (SAT) ) A compromise between low EON / EOFF loss to fully optimize circuit performance. Direct-bonded copper (DBC) substrates support high currents, minimizing the effects of parasitic inductance, enabling designers to achieve high switching speed and provide 3000 Vrms isolation voltages with a creepage distance of 12.7mm.

In addition, ON Semiconductor has introduced a novel, fully optimized, ultra-compact, intelligent power stage (SPS) multi-chip module, the FDMF3170, for DC-DC step-down conversion in servers, data centers, artificial intelligence accelerators, and telecom equipment. Device. It integrates two high-performance power MOSFETs based on ONSemiconductor's PowerTrench® Technology and an intelligent driver with high-precision current sensors for optimal processor performance.

Power Conversion and Motor Control Technology Demonstration at Electronica

The two new power modules will be demonstrated at the ON Semiconductor booth during the Electronica show, highlighting the importance of semiconductor-based energy-efficient solutions for developing successful power conversion and motor control (PCMC) designs. The booth demonstration will highlight ON Semiconductor's solutions to pioneering industrial power, solar and motor drives and will include a robotic display and solar and battery energy storage devices.

ON Semiconductor offers the broadest lineup of power semiconductor devices in an innovative package format that supports the world's cleaner, more reliable and cost effective energy design. The lineup includes devices based on advanced wide band gap (WBG) materials, MOSFETs for all motor types, IGBTs, PIMs and IPMs, and fully integrated drivers. Together, these devices continue to drive the energy revolution by dramatically improving the energy-efficient, reliable, compact and low-cost power solutions required for modern applications.
