Product Overview
- Part Number
- TPS61161ADRVR
- Quantity Available
- 10,000
- Manufacturer
- Luminary Micro / Texas Instruments
- Catalog
- PMIC - LED Drivers
- Description
- IC LED DRVR RGLTR DIM 700MA 6SON
Get Quote
Documents & Media
- Datasheets
- TPS61161ADRVR
Product Attributes
- Applications :
- Backlight
- Current - Output / Channel :
- 700mA (Switch)
- Dimming :
- PWM
- Frequency :
- 600kHz
- Internal Switch(s) :
- Yes
- Mounting Type :
- Surface Mount
- Number of Outputs :
- 1
- Operating Temperature :
- -40°C ~ 85°C (TA)
- Package / Case :
- 6-WDFN Exposed Pad
- Packaging :
- Tape & Reel (TR)
- Part Status :
- Active
- Series :
- -
- Supplier Device Package :
- 6-WSON (2x2)
- Topology :
- Step-Up (Boost)
- Type :
- DC DC Regulator
- Voltage - Output :
- 38V
- Voltage - Supply (Max) :
- 18V
- Voltage - Supply (Min) :
- 2.7V
Description
TPS61161ADRVR LED Driver IC 1 Output DC DC Regulator Step-Up (Boost) PWM Dimming 700mA (Switch) 6-WSON (2x2) manufactured by Texas Instruments is available at Asourcing Electronics.
With a 40-V rated integrated switch FET, the TPS61160A/61A is a boost converter that drives LEDs in series. The boost converter runs at 600-kHz fixed switching frequency to reduce output ripple, improve conversion efficiency, and allows for the use of small external components.
TPS61161ADRVR Features
• Input Voltage Range: 2.7 V to 18 V
• 26-V Open LED Protection for TPS61160A
38-V Open LED Protection for TPS61161A
• 200mV Reference Voltage With ±2% Accuracy
• PWM Interface for Brightness Control
• Built-in Soft Start
• Up to 90% Efficiency
• 2-mm × 2-mm × 0.8-mm 6-Pin WSON Package With Thermal Pad
TPS61161ADRVR Applications
• Cellular Phones
• Portable Media Players
• Ultra Mobile Devices
• GPS Receivers
• White LED Backlighting for Media Form Factor Display
If you want to buy the TPS61161ADRVR, please feel free to contact us to check the stock availability, latest price, date code, delivery, etc.
Original label of TPS61161ADRVR by Texas Instruments
Original label of TPS61161ADRVR by Texas Instruments
